Base on our years of water treatment technical experience, Aimer apply
itself to seawater desalination technology research and the production
applications.
Aimer has a deep understanding of ship operations, so after continues
innovation Aimer develop the patent vessel seawater desalination
equipment which bring healthy and delicious pure water.
Features
1. High quality ceramic filter which can highly remove animalcule,
produce water stably and can be repeatedly used.
2. Advanced frequency converse seawater treatment device, which can
efficiently kill the Algal and bacterium flora, Anti and remove dirt.
3. Small size, light weight, fit for ocean-going ships.
4. Coconut active carbon, so water is sweet and water yield is stable.
Specifications
|
Spec. |
Flowrate (m³/D) |
Salt Rejection (%) |
TDS in product water(mg/L) |
Working pressure(MPa) |
Power (KW) |
Feed water temp.(℃) |
Weight(kg) |
Size(LxWxH) |
|
SW-RO1 |
1 |
≥98 |
≤700 |
3.5~6.5 |
1.1 |
5~40 |
120 |
580x440x1600 |
|
SW-RO2 |
2 |
≥98 |
≤700 |
3.5~6.5 |
1.5 |
5~40 |
130 |
580x440x1600 |
|
SW-RO3 |
3 |
≥98 |
≤700 |
3.5~6.5 |
1.5 |
5~40 |
140 |
580x440x1600 |
|
SW-RO5 |
5 |
≥98 |
≤700 |
3.5~6.5 |
2.2 |
5~40 |
150 |
650x440x1600 |
|
SW-RO10 |
10 |
≥98 |
≤700 |
3.5~6.5 |
5.5 |
5~40 |
220 |
950x600x1600 |
Technical parameter
1. High-pressure pump: Italy AR pump
2. Salt rejection 698 %
3. Recovery: 10%
4. Feed water pressure: 0.1～0.3 Mpa
5. Feed water temperature: 5～40℃
6. Wet parts of pump: Brass
7. Low pressure pipe: UPVC pipe
8. High pressure pipe: SUS316 pipe
9. Frame: SUS304
10. Control method: Manual
11. TDS in product water: 9700 mg/L
