Model No. |
UF8040 |
|||
|
Hollow fiber material |
PAN |
PP |
PS/PES |
PVDF |
|
Dimensions |
Φ200X1480mm or as clients’ requirement |
|||
|
Socket connector size |
DN40 |
|||
|
Hollow fiber ID/OD(mm) |
1.0/ 1.6 |
0.4 / 0.5 |
0.8/1.2 or 1.0 / 1.6 |
0.7mm / 1.3mm |
|
Filtration type |
Inside-out |
Outside-in |
Inside-out |
Outside-in |
|
Effective membrane area |
20m2 |
42m2 |
20m2 |
40m2 |
|
Intercept molecular Weight (Daltons) |
50000～100000 |
100000 |
10000～100000 |
100000 |
|
Initial flux T/H |
>5 |
>6.0 |
>5 |
>6.0 |
|
Designed flux T/H |
1.0-1.4 |
1.4-1.8 |
1.0-1.4 |
1.4-1.8 |
|
End seal material |
Epoxy resins |
|||
|
Outer shell material |
UPVC |
|||
|
Max. Feed pressure |
0.3mpa |
|||
|
Recommendatory feed pressure |
0.06-0.15mpa |
|||
|
Trans Memb Pressure |
0.04-0.08 mpa |
0.04-0.15mpa |
0.04-0.15mpa |
0.04-0.15mpa |
|
Working temperature |
5-45℃ |
|||
|
Feed water turbidity |
<50NTU |
<70 NTU |
<50 NTU |
<70 NTU |
|
PH range |
3-10 |
2-13 |
2-13 |
2-13 |
|
Filtrate SDI |
<1 |
<2 |
<1 |
<2 |
|
Filtrate Turbidity |
<0.1 NTU |
<0.2 NTU |
<0.1 NTU |
<0.2 NTU |
|
Coliform & Bacteria removal |
99.9% |
|||
|
Life Span |
One year, operated strictly under the above technical data |
|||
|
Remark: Initial output flow rate test under purified water at 25℃ and 0.1 Mpa conditions |
||||
